HDMI+VGA +AV+Audio LCD TV board + G173HW01 V.0 with 1920*1080+LVDS cable +Remote control and receiver +OSD keypad with cable

100 % of buyers enjoyed this product!
Availability: in stock
Price:  US $105.00 / piece
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Sort By

Top-rated Seller

Share:

HDMI+VGA +AV LCD TV board +LVDS cable +Remote control and receiver +OSD keypad with cable+ G173HW01 V.0

VGA+HDMI+AV+USB+TV+Audio board

Brief description of LCD panel

Panel module

G173HW01 V.0

Panel size

17.3 inch

Resolution

1920(RGB)X1080(FHD)

Aspect ratio

16:9(W*H)

Surface

Glare(Haze 0%,Hard coating (3H))

Active Area

381.89*214.81 mm(W*H)

Bezel Area

385.09*218.01mm (W*H)

Outline Dimension

403.00*240.00mm (W*H)

Outline Depth

12.5+0.5 mm

Display module

TN, Normally White Transmissive

Brightness

400cd/m2 (Typ.)

Contrast Ratio

600:1(Typ.)(Transmiss)

Display Color

16.7M(6—bit+Hi+FRC)

Color Gamut

72%

Response Time

37/3(Typ.)(Tr/Td)(ms)

Viewing Angle

80/80/60/80(Typ.)(CR>10)(L/R/U/D)

Vertical Frequency

60HZ

Lamp Type

WLED

Lamp Driver Board

Signal Category

LVDS

Signal Glass

LVDS(2ch ,8-bit)

Pin Configuration

LVDS-30P2C88-200A

Input Voltage For Panel

1.2/1.4A(Typ.Max)

Input Current For Panel

5.0/6.0W(Typ.Max)

Pane Power Consumpation

Interface Type

Connector

Interface Brand

HRS

Interface Module

MDF76TW-30S-1H

Interface Pin Pitch

1.0mm

Interface Pins

30Pin

Amount Per Box

10Pcs

Box Size

524*321*360mm (L*W*H)

Box Gross Weight

Brief description of LCD controller board

1.Main chip : TSUMV56RUU-Z1

2.Support VGA+HDMI+AV+Audio+USB+TV(PAL, SECAM)

3.Support LCD panel interface :Single/Dual Channel LVDS

4.Support Resolution: Up to 1920X1200@60HZ

5.Working voltage:+12V

6.Power to panel:+3.3V/+5V/+12V

7.OSD language:English, French, German,Italian, Spanish, Portuguese, Russian(optional)

8.Keyfunction:CH-/CH+/MENU/VOL-/VOL+Souce/Power(Control by remote control)

9.Audio output power:2X8Ω2W

10.Support IR Control

11.Standby Power Consumption :<0.3W

12.Support USB firmware upgrade and media player function

13.Dimension(mm):188.5(L)*42.3(W)*14(H)

Package content

1*LCD panel G173HW01 V.0

1*LCD controller board M6-V5.1

1*LVDS cable

1*OSD keypad with cable

1*Remote control and receiver

1*Backlight cable

If you need more detailed information of the LCD panel, please contact me or send Email to me .my skype is :elice.yu Thanks !
