Input Voltage : 110-240Vac
Frequency/current: 47-63Hz / 6.5A
Charge voltage: 88.2V
Charge current: 4.5 A
Charge method: CC/CV
Working Temperature: 0°C to 45°C
Storage Temperature: -20°C to 50°C
Charging voltage rated : 88.2 ± 0.3 V
Charging Current rated : 4.5± 0.5 A
Input pulg/Output pulg : Refer to the following plug pictures
******Charge Voltage and Current can be customized by Customers requirement.
If you cannot find what you need,Please Leave Words of Input AC Plug And Output DC Plug,
Like: ‘AC:Number 5,DC:G’,Thank You!!!
FOR Nominal Voltage 72V (77.7V), Rated Capicaty:10Ah- 35Ah battery pack, 72V (77.7V) electric bike
UPS powers (21 series lithium li-ion lipo battery pack), Rechargeable Battery, Lead acid/LifePO4/Li-ion Battery,Electric Tools,
Garden Power Tools,Cleaning machine,Ebike,Golf cart ,Electric Scooter,ntelligent Balance Car Folding Bicycle ,UPS Power Supply etc.
● Stable MTBF:> 30000 H
● Small Size: 205 * 121 * 50mm
● Light Weight: 1.2kg
● Delivery Time: 2-5 working days
● Material:Metal Aluminium Case
● After-sales service: 36months Warranty
● Protection function: Over voltage / Over temperature / Over current / Short circuit and Polarity
● The indicator of LED: Red is charging, green is charge finished or prepare charging
● Light, Small, Stable, High-Efficiency, Safe, etc.Precise limit of voltage & current, qualified fully charged
and avoid over charge
1)Input and output filter electrolytic capacitor use withstand temperatures -40 to +105℃,with Low Impedance ,High
reliability,Long useful life,High rip-ple capability,etc features.
2)Input Bridge KBP406 rectifiers Can withstand average Forward Rectified Current 4A,peak forward surge current
130A,Bl-ocking Voltage 600VDC
3)The main power transformer adopts EC40 core, PC40 material,High efficiency, low iron loss,Enough power
capacity,Have sufficient power margin.
4)Using aluminum heat sink,Good thermal design,can better cool the power device, Consistent with the principle of hot
air flow,extend the service life
